Swingcut 240
Article-No. | 1012.200 |
Power | 240 W (0.32 hp) |
Idling speed | 35'000 rpm |
Compliance radial in two directions | ± 3.8° / ± 8.5 mm (at collet) |
Compliance toque | 2.4 Nm (1.77 ft lbs) bei 6 bar (87 psi) |
Compliance force | 19 N (4.3 lbs) at 6 bar (87 psi) (at collet) |
Feed forward rate | 5 - 250 mm/sec. |
Air consumption | 7.5 l/s (15.9 cfm) |
Collet | Ø 6 mm |
Weight | 2.2 kg (4.9 lb) |
