Finishtool Serie 300
Type | FINISHTOOL 320 | FINISHTOOL 321 | FINISHTOOL 331 | FINISHTOOL 333 |
Article-No. | 3450.210 | 3450.211 | 3450.231 | 3450.233 |
Power | 1.2 kW | 1.2 kW | 820 W | 820 W |
Idling speed | 2'300 rpm | 5'200 rpm | 2'350 rpm (r) | 3'850 rpm (r) |
Rated speed | 1'200 rpm | 2'700 rpm | 1'200 rpm (r) | 1'970 rpm (r) |
Compliance movement | 34 mm (radial) | 34 mm (radial) | 34 mm (radial) | 34 mm (radial) |
Compliance force * at 6 bar | approx. 140 N | approx. 140 N | approx. 140 N | approx. 140 N |
Feed forward rate | 50 - 200 mm/s | 50 - 200 mm/s | 50 - 200 mm/s | 50 - 200 mm/s |
Air consumption | 22.5 l/s | 22.5 l/s | 17.5 l/s | 17.5 l/s |
Motor shaft | Ø19 x 40 mm | Ø19 x 40 mm | Ø19 x 40 mm | Ø19 x 40 mm |
Wheel diameter | 100 - 250 mm | 100 - 250 mm | 100 - 250 mm | 100 - 250 mm |
Weight | 8.2 kg | 8.2 kg | 8.2 kg | 8.2 kg |
* without dead load
(r) rotating direction reversible
